GF Signet Paddlewheel 515 Rotor-X

 Type 515 Rotor-X Standard Mount Paddlewheel

Simple to install with time honored reliable performance, Model 515 Rotor-X paddlewheel flow sensors are highly repeatable, rugged sensors that offer exceptional value with little or no maintenance. The output signal of the This  a sinusoidal frequency capable of driving a self-powered flowmeter (Model 5090). The wide dynamic flow range of 0.3 to 6 m/s (1 to 20 ft/s) allows the sensor to measure liquid flow rates in full pipes and can be used in low pressure systems.

The Model 515 sensors are offered in a variety of materials for a wide range of pipe sizes and insertion configurations. The many material choices include PP and PVDF make this model highly versatile and chemically compatible to many liquid process solutions. Sensors can be installed in up to DN900 (36 in.) pipes using Signet's comprehensive line of custom fittings. These custom fittings, which include tees, saddles, and weldolets, set the sensor to the proper insertion depth into the process flow. The sensors are also offered in configurations for wet-tap and intrinsically safe installation requirements.

Advantages:

·         Easy to replace rotor

·         Installs into pipe sizes DN15 to DN900 (½ to 36 in.)

·         Highly repeatable output

·         Self-powered

·         Simple, economical design

·         Operating range 0.3 to 6 m/s (1 to 20 ft/s)

·         Wide Turndown Ratio of 20:1

·         Chemically resistant materials

Fields of Application:

·         Chemical Production

·         Liquid Delivery Systems

·         Pump Protection

·         Filtration systems

·         Pure Water Production

·         Not suitable for gases

Standards:

·         RoHS Compliant
