AquaMatic K537 Composite Valves

 AquaMatic K537 Composite Valves

3” inch "Y"pattern diaphragm valves
Glass-filled thermoplatic body and cap intended for corrosive applications

Features

·         Two dynamic o-rings on the shaft, with a vent in between the o-rings to prevent damage to the diaphragm

·         Female socket weld connectors for easy installation and the ability to remove the valve without disrupting the service piping

·         Cap held by a retaining ring, eliminates screws and nuts

·         No external metal parts to corrode in aggressive atmosphere

·         Valve bodies provided with molded pads can be used to support piping manifold

·         Reinforced diaphragms are pre-formed and stress relieved to maximize responsiveness and product life

·         Ideal for corrosive applications including deionized water, acids, caustis and harsh chemicals that would rapidly corrode metal valves

·         Can be actuated with either air or water as control fluid

Options

·         Fully adjustable limit stop from full-open to full-closed, with a position indicator to show valve position

·         Position indicator

·         Spring assist (open or closed)

·         Seal and diaphragm materials available

·         Normally open or closed

·         Externally normally closed

We have stock on Ruko SB1/23 Vila Nusa Indah 5 – Cibubur – Jakarta :

·         AquaMatic K534-X200-14000 PN:1070308 With Kit PN:1070419

·         AquaMatic K535-X2B2-14000 PN:1071353 With Kit PN:1070425

·         AquaMatic K537-X2B2-14000 PN:1071382 With Kit PN:1070431

·         AquaMatic K537-X200-14000 PN:1070316 With Kit PN:1070431

Indent for unit :

·         AquaMatic K531-X200-14000

·         AquaMatic K531-X210-14000

·         AquaMatic K531-X201-54000

·         AquaMatic K531-X200-54000

·         AquaMatic K531-X201-64000

·         AquaMatic K531-X200-64000
